Everything you need for ventilating your grow box in one complete set
Everything you need for proper ventilation of a small grow box: With the AC Infinity Complete Exhaust Air Set 350 m³/h, you get all the components necessary for air supply. The set is suitable for boxes and tents with a floor space of up to 60 x 60 cm.
The set includes a CLOUDLINE series inline fan with 10-step control. Its stator blades, double hydrodynamic wind circuits, and mixed flow design guarantee you a powerful air flow in any environment. Double ball bearings ensure a long service life of up to 67,000 hours, and the plastic base minimizes possible vibration noise. Maintenance and cleaning are made easy: you can simply remove the motor housing from the mounted frame.
The set also includes a carbon filter in a red brass finish with Australian activated carbon that effectively retains odors. The activated carbon has an IAV value of 1200+, which means it cleans the airflow with a higher adsorption rate and longer service life. The powder-coated red brass surface also contributes to this by preventing corrosion even in high humidity. The fan and carbon filter are connected by a flexible pipe system with four protective layers. The supplied pipe clamps, pre-filter cloth, rope clamps, and suspension straps make installation of the complete exhaust air set very easy.
Technical Details:
Fan
- Connection: 100 mm
- Dimensions: 18.8 x 30.3 x 17.6 cm
- Power cable length: 183 cm
- Cable length to controller: 183 cm
- Total air flow: 350 m3/h
- Operating noise: 29 dBA
- Static air pressure: 324 Pa
- Electrical voltage: 100 – 240 V (50/60 Hz)
- Maximum power: 28 W
- Average power: 21 W
- Current: 0.4 A
- Plug: Euro plug
- Humidity range: 35–85%
- Temperature range: 0 - 60 ℃
- Protection class: IP44
- Service life: 67,000 hours
- Certifications: CE, RoHS, ETL
Activated carbon filter
- Maximum air flow: 357 m3/h
- Carbon type: Australia Virgin RC412
- Quality: 1200+ IAV
- Humidity range: 35–75%
