The S&P tube fan TD-2000/350 Ecowatt: High air throughput with low power consumption and quiet operation
- With non-combustible sound insulation lining and metal housing
- Flat design - perfect for use in grow boxes
- EC motor, volume flow up to 1660 m³/h
- Speed adjustable via signal input 0-10 V or internal potentiometer
- Motor can be easily removed for maintenance and cleaning
The TD-2000/350 Ecowatt is equipped with a modern and energy-saving EC motor, is only around 37 cm high, operates quietly and is therefore perfect for your indoor grows.
Especially quiet thanks to internal sound insulation, EC motor and semi-radial aluminium impellers
The ingenious design of the fans from Soler & Palau ensures particularly quiet operation. The aluminium impellers are statically and dynamically balanced and the high-quality EC motor with sealed ball bearings is designed for continuous operation. The special sound insulation lining is non-flammable (A2) and absorbs most of the noise generated. At a volume flow of 790 m³/h, the TD-2000/350 Ecowatt emits only 31 dB(A). You can of course reduce this value even further with a sound-insulated exhaust air hose. The fans from S&P offer outstandingly quiet running. You don't have to worry about the humming and vibrations that often occur with standard fans. The already very low-vibration EC motor is also fitted with vibration-damping seals and the aerodynamically optimised airflow channel reduces the generation of noise. With a length of just 82.5 cm and a height of only 37.3 cm, this fan fits well in smaller grow rooms and grow boxes.
Infinitely variable, easy to clean and maintain
The TD-2000/350 Ecowatt tube fan is equipped with an internal potentiometer for infinitely variable speed control. It also has an input for external control signals with 0-10 volts. At full speed, the tube fan has a maximum air flow rate of 1660 m³/h and consumes only an economical 247 watts. To service or clean the fan, you can simply remove the motor from the housing. You don't need to remove the pipework for this.
Scope of delivery:
- 1x S&P pipe fan TD-2000/350 Ecowatt
Technical details:
- Voltage: 230 V
- Power consumption: max. 247 W
- Weight: 14 kg
- Length: 825 mm
- Height: 373 mm
- Width: 432 mm
- Air flow: 0-1660 m³/h
- Sound pressure level: max. 41 dB(A)
- Connecting flange: 315 mm
- Engine: EC
S&P TD silent Ecowatt Instruction Manual
S&P TD silent Ecowatt Data Sheet
| Connection: | 315mm |
